15
Introduction
Nomenclature
Eyecup (→82)
Viewfinder eyepiece
Main switch (→29)
〈MENU〉 Menu button
(→32)
〈INFO.〉 Info button
(→60, 100)
〈JUMP〉 Jump button
(→99)
〈 〉 Index/
Enlarge button
(→98, 99)
〈 〉 Playback
button (→40, 98)
LCD monitor (→32)
〈 〉 Erase button (→43, 104)
Tr ipod socket
Date/time battery compartment cover (→113)
〈 〉 Set button (→32)
〈 〉 Quick control dial (→31)
Battery chamber cover
(→24)
Battery chamber cover
release lever (→24)
CF card slot
cover (→28)
Strap mount
(→21)
Access lamp
(→28)
〈 〉 AF point
selection button (→57)
〈 〉 AE lock /FE lock button
(→80, 90)
Quick control dial switch (→31)
Dioptric adjustment knob (→36)
CF Card Slot Cover
CF card slot
(accepts card type1and 2)
(→28)
CF card eject button (→28)
