Handling rolls
Loading Rolls in the Roll Holder Slot
Once a roll is in the Roll Holder , follow these steps to load the roll in the Roll Holder Slot .
1. Open the T op Cover and lift the Ejection Guide .
2. With the edge of the roll facing forward as shown, insert the Roll Holder shaft (a) into the guide
grooves (b) of the Roll Holder Slot on both sides.
Caution
• Be careful not to drop the roll and hurt yourself when loading it.
• Be careful not to pinch your ngers between the Roll Holder shaft (a) and the guide grooves
(b) when loading rolls.
At this point, to advance the roll, see “Loading the Roll in the Printer”. (→P .121)
120 Handling Paper
