Output Stacker
Stowing the Output Stacker
Stow the Output Stacker if you will use the Media T ake-up Unit or if you will not use the Output Stacker
for an extended period.
1. When the Output Stacker is in the position used when storing printed documents (a), lift the front
Basket Rod gently to release the lock, lower the stacker toward the front (b), and push it all
the way back.
2. Remove the front Basket Rod from the left and right Basket Arms . Roll up the Basket Cloth and
put it at the back of the Bottom Stand Stay .
Important
• When using the optional Media T ake-up Unit , position the Basket Cloth and Basket Rod so they do
not interfere with the Media T ake-up Sensor (indicated by the dashed line).
162 Handling Paper
