Installation Procedures

The procedures to install Print Plug-In are as follows.

1. Insert the User Software CD-ROM into the CD-ROM drive to start the installer.

Note

• If the installer screen does not appear, open the CD-ROM icon in My Computer and click on set-

up.exe to open the icon.

2. Click imagePROGRAF Print Plug-in button.

3. Click the appropriate Install button for your Print Plug-In.

•

For 32-bit Windows

Windows Software

Print Plug-In for Photoshop/Digital Photo Professional

iPF6300S Installation Procedures

309
