5. Free Layout main window is displayed.

Free Layout Main Window

The Free Layout main window consists of the menu and tool bars, layout area and dialog areas.

Note

• You can use the View menu to show or hide the tool.

Mac OS X Software

Free Layout

iPF6300S Free Layout Main Window

551
