Click the Close button to return to Print Plug-In.

Main Sheet

You can use this sheet to perform basic settings such as selecting a printer, setting the media type, or adjusting image quali-

ty.

•

Printer

The printer types are displayed.

•

Select button

Click this button to display the Select Printer dialog box.

When you click the OK button after selecting the printer in the Select Printer dialog box, you can change the printer

that corresponds with Print Plug-In.

•

Media Type

This allows you to select the media type.

For more information about Media Type, see "Customize Media Settings." →P.659

Note

• Always select media type that is actually set in the printer. When the media you chose is different from

the media set in the printer, you may not receive the desired print results.

Mac OS X Software

Print Plug-In for Photoshop/Digital Photo Professional

iPF6300S Main Sheet

619
