5. Click the Quit button.

Starting from Photoshop

Follow the procedure below to start the Print Plug-In from Photoshop.

1. Start Photoshop.

2. Open the image that you wish to print.

3. If required, select the print range.

Note

• Images for use with Print Plug-In are less than 60,000 pixels in width and height. Reduce the selec-

tion range or reduce the image with processing for images more than 60,000 pixels in width and

height, and then attempt step 3.

Mac OS X Software

Print Plug-In for Photoshop/Digital Photo Professional

iPF6300S Starting from Photoshop

613
