The Update Media Types wizard is started at this point. For details on the procedure to update paper information

using the Update Media Types wizard, see "Updating Media Types."

→P.697

Important

• Be sure to click the Update button. If you do not, your changes will not be applied to the printer and

printer driver.

Switching Media Types Display Show/Hide

Open the Edit Media Types dialog box.

Mac OS X Software

Media Configuration Tool

iPF6300S Switching Media Types Display Show/Hide

693
