2. Place the pointer inside the selection box of the object to show the crosshair handle, and drag it to move the object.

Rotating an Object

You can rotate the object.

1. Select an object.

2. Select Rotate Left or Rotate Right from the toolbar.

Alternatively, you may click on the Rotate check box in the Format Dialog Box →P.573 then select Rotate Right

or Rotate Left, and click the OK button.

Note

• When several objects are selected, you cannot select Rotate.

Mac OS X Software

Free Layout

iPF6300S Rotating an Object

577
