2. Press â–² or â–¼ to select Roll Paper, and then press the OK button.
Note
• If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press â–² or â–¼ to select "Yes", and then press the OK button. Remove the paper and go to the next
step.
3. Open the Roll Feed Unit Cover.
4.
Holding the Roll Holder flange (a), load the Roll Holder shaft into the guide grooves (b) on both sides of the Roll
Holder Slot. At this time, load the shaft so that the color of the Roll Holder shaft (c) matches the color of the guide
groove.
Caution
• Do not release the flanges until you load the holder fully in the Roll Holder Slot. Rolls are heavy, and
dropping a roll may cause injury.
• Be careful not to pinch your fingers between the guide grooves (b) and the Roll Holder shaft (c) when
loading rolls.
Handling Paper
>
Handling rolls
>
iPF6300S Loading Rolls in the Printer
6
