5. Open the Roll Feed Unit Cover.

6. Using both hands, rotate the Roll Holder toward the back to rewind the roll.

7. Holding the Roll Holder flange (a), remove the holder from the Roll Holder Slot.

Note

• For instructions on removing rolls from the Roll Holder, see "Removing Rolls From the Roll Hold-

er." →P.792

Handling Paper

Handling rolls

iPF6300S Removing the Roll from the Printer

791
