9. Click the Matching tab to display the Matching panel.

10. Make sure Driver Matching Mode is selected in A Matching Mode.

11. In B Matching Method, select Monitor Matching.

12. In C Color Space, select the color space used when displaying the file in the source application.

13. In D Monitor White Point, select the white point set on the monitor.

Note

• For greater precision in monitor matching, we recommend configuring the settings for ambient light

matching. (See "Printing in Ideal Colors for Light in the Viewing Environment.") →P.850

14. Click OK.

15. Confirm the print settings and print as desired.

Adjustments for Better Print Quality

Color adjustment

iPF6300S Printing Images to Match Monitor Colors (Mac OS X)

873
