5. Fix the Large Pulley on top right of the Compartment.
• 1 Screw (RS tightening; M4x8)
• 1 Washer
1x
6. Attach the Large Pulley and then put the Short Lifter Wire along the groove.
• 1 Parallel Pin
CAUTION:
Put the Short Lifter Wire in the groove R side.
RR
NOTE:
Pull the Short Lifter Wire from bottom right of the Compartment and attach it without slackness.
4. Disassembly/Assembly
77
