Canon PowerShot A430 - Before Using the Camera-The Components Guide; Front View

12
Before Using the Camera—The Components Guide
Front View
Power Button (Basic Guide p. 2)
Shutter Button (Basic Guide p. 4)
Speaker
Flash (Basic Guide p. 8)
Microphone (p. 62)
Viewfinder Window (p. 19)
A/V OUT (Audio/Video output) Terminal (p. 71)
Wrist Strap Mount
AF-assist Beam (p. 24)
Red-Eye Reduction Lamp (Basic Guide p. 8)
Self-Timer Lamp (p. 35)
Lens
Attaching the Wrist Strap
