Carrier C708 - Door and Beater Assembly (Model C709

97
Models C708/C709/C716/C717
Parts
Door and Beater Assembly (Model C709)
ITEM DESCRIPTION PART NO.
1 HANDLE A.-DRAW-WELDED X56246
2 O -RING-1/4 OD X .070W 50 015872
3 SCREW -ADJUSTMT-5/16-24 056332
4 NUT-STUD BLACK 3.250” 058765
5 NUT-STUD BLACK 2.563“ 058764
6 DOOR A.-W/BAFFLE X57332 -SER
7 VALVE A.-DRAW X55820
8 O-RING-DRAW VALVE-S.S. 014402
ITEM DESCRIPTION PART NO.
9 PIN-HANDLE-SS 055819
10 GASKET -DOOR HT 4” -DBL 048926
11 BEARING-FRONT 050216
12 BEATER A. -3.4 QT HELICORE X31761
13 BLADE -SCRAPER-PLASTIC 035174
14 SHAFT -BEATER 056078
15 SEAL -DRIVE SHAFT 032560
