113
+ Available Separately
Models C708/C709/C716/C717 Parts List
DESCRIPTION PARTS
UPDATE
REMARKSWARR.
CLASS
C716
QTY.
C708
QTY.
PART
NUMBER
CAP--VALVE BODY SS 056874--14 1 2 103
+CLIP--RETAINER--MIX PUMP 044641 1 2 103
CYLINDER A.--PUMP--HOPPER--S.S. X57025 1 103
GASKET--SIMPLIFIED PUMP VALVE 053527 1 2 000
O--RING--2--1/8 OD X .139W--#225 020051 2 4 000
PIN A.--RETAINING X55450 1 2 103
+PIN--COTTER--HAIRPIN--1/8DIA 044731 1 2 103
PISTON 053526 1 2 103
RECEIVER A.--REFRIG.AC*C708/709 X59351 1 103
RELAY--3 POLE--20A--208/240 50/60 012725--33 1 2 103
RELAY--DPDT 100UA TO 7A 1/8HP 052111--03 1 2 103 BEATER INTERLOCK
RELAY--DPDT--24VAC--30A@277V 054703--03 2 103 HOT GAS SOLENOIDS
RELAY--MTR START TI#4CR--1--625 039725--27 1 2 103
SANITIZER KAY--5 125 PACKETS 041082 1 1 000
SHAFT A.--DRIVE--MIX PUMP--HOPPER X41947 1 2 103
O--RING--1--3/4 OD X .139W 008904 1 2 000
CRANK--DRIVE--HOPPER MIX PUMP 039235 1 2 103
SHAFT--DRIVE--MIX PUMP--HOPPER 041948 1 2 103
O--RING 1/2 ID X .139W 048632 2 4 000
SHAFT--BEATER *C706/C707* 056078 1 103
+SEAL--DRIVE SHAFT 032560 1 000
SHAFT--BEATER 032564 2 103
+SEAL--DRIVE SHAFT 032560 2 000
SHELF--TRAY--DRIP *C706* 056076 1 103
SHELL A.--INSULATED *C708/C709 X56969 1 512
+STUD--NOSE CONE *C602* 055987 4 103
SHELL A.--INSULATED *C716* X59820 1 512
+STUD--NOSE CONE *C602* 055987 4 103
SHIELD--SPLASH *RD30* 049203 1 103
SHIELD--SPLASH--WIRE--19--3/4 L 033813 1 103
SHROUD A.--CONDENSER *C708/C709 X56922 1 103
SLEEVE A.--MIX PUMP *HT*MCD X44761 1 2 103
+NUT--PUMP SLEEVE *8751*HT* 036933 1 2 000
C708/C716
