Carrier C708 - Operator Parts (Model C717)

83
Models C708/C709/C716/C717
Parts
Operator Parts (Model C717)
ITEM DESCRIPTION PART NO.
1 COVER-HOPPER 053809-1
2 BLADE A.-AGITATOR X56591
3 ORIFICE 022465-100
4 TUBE A.-FEED-SC-INNER-3/16H X32824-3
5 TUBE A.-FEED-OUTER-HT X34641
6 O -RING-.643 OD X .077 W 018572
7 PANEL-REAR 059917
8 PANEL-SIDE*RIGHT 059907
9 PAN-DRIP 12.5 059736
10 PANEL A.-FRONT X59920
ITEM DESCRIPTION PART NO.
11 PANEL A.-FRONT X59836
12 STUD -NOSE CONE 055987
13 FILTER-AIR-POLY-FLO 052779-11
14 PANEL A.-FILTER-LOUVERED X59928
15 SCREW-1/4 -20 X 3/8 RHM-SS 011694
16 DEFLECTOR -BLOWER EXHAUS 059929
17 SHIELD-SPLASH -WIRE-19 -3/4 L 033813
18 TRAY -DRIP-19-5/8 L X 4 -7/8 033812
19 PAN -DRIP 19-1/2 LONG 035034
20 PANEL -SIDE-LEFT 059906
