Carrier C708 - Operator Parts (Model C709)

75
Models C708/C709/C716/C717
Parts
Operator Parts (Model C709)
ITEM DESCRIPTION PART NO.
1 PANEL-SIDE-LEFT 056963 -SP1
2 PAN-DRIP 11-5/8 LONG 027503
3 PIN-RETAINING-HOPPER CVR 043934
4 COVER-HOPPER *BLACK 053809-1
5 BLADE A.-AGITATOR X56591
6 TUBE A.-FEED-OUTER-HT X34641
7 PANEL-REAR 056077-SP1
8 ORIFICE 022465-100
9 SCREW -1/4 -20X3/8 RHM-SS 011694
ITEM DESCRIPTION PART NO.
10 PANEL A-SIDE-RIGHT X57871
11 PANEL A.-FRONT-UPPER X59423
12 PANEL A.-FRONT-LOWER X58955
13 STUD -NOSE CONE 055987
14 SHELF -TRAY-DRIP 056076
15 TRAY -DRIP 056858
16 SHIELD-SPLASH 049203
17 TUBE A. -FEED-SC -INNER X32824-2
