Carrier C708 - Box A.-Cap & Relay - X59499-27 (Model C716)

90
Parts
Models C708/C709/C716/C717
Box A.-Cap & Relay - X59499-27 (Model C716)
ITEM DESCRIPTION PART NO.
1 CAPACITOR-START
189-227UF/33
033044-1
2 CAPACITOR-RUN 40MF/440V 036049
3 STRAP-CAPACITOR 7-11/32 037890
4 SCREW -6-32X5/8 TAPTITE PAN 041250
5 CONNECTOR-BX 3/4 STR-2
SCREW
031231
ITEM DESCRIPTION PART NO.
6 SCREW -8-32X3/8 TAPTITE-HEX 041951
7 RELAY-START-COMPRESSOR 052401-27
8 SCREW -6-32X1 -1/4 RD HD 017310
9 BLOCK -TERMINAL 2P L1,L2 039422
10 LUG-GROUNDING 4-14GA
WIRE
017667
