15
Models C708/C709/C716/C717
Introduction
Air/Mix Pump Reset Mechanism
(C708 & C716 On ly)
C708: The reset button for the pump is located on
the left side.
C716: The reset buttons for the pumps are located
in the rear panel.
The reset protects the pump from an overload
condition. Should an overload occur, the reset
mechanism will trip. To reset the pump, press the
reset button firmly.
W ARNING: Do not use metal objects to
press the reset button. Failure to comply may result
in severe personal injury or death.
Condenser Fan Motor
The condenser fan motor is driven by the software.
The L1 to the fan is connected to the interface board
at J6-6. The condenser fan is programmed to run
any time the compressor is on and to stay running
for 30 seconds after the compressor cycles off. The
fan motor runs constantly through heat cycles
regardless of the compressor status, then cycles off
30 seconds after the compressor cycles off at the
end of the Heat Cycle and subsequent Standby
Mode.
