CHAPTER 10 – SPECIFICATIONS
10-4
TRANSMISSION
ZF Transmission
FULL POWER SHIFT Type with Torque Converter, 6 (six) speed forward and 3 (three) speed reverse. Modulated gear
shifts, reduction and reverse protection, gearshift electronic control mounted on the right hand-side console.
FUNK Transmission
FULL POWER SHIFT Type with 8 (eight) Forward and 4 (four) Reverse speeds. Shift modulation (forward and reverse)
and clutch release. Gear selection by means of electronic command.
Gear
ZF FUNK
Forward Reverse Forward Reverse
Ratio km/h (mph) Ratio km/h (mph) Ratio km/h (mph) Ratio km/h (mph)
1 5,202 5,0 (3,1) 4,933 5,3 (3,3) 6,54 4,2 (2,6) 6,54 4,2 (2,6)
2 3,367 7,7 (4,8) 2,078 12,5 (7,8) 4,68 5,8 (3,6) 3,31 8,3 (5,2)
3 2,191 11,8 (7,3) 0,895 28,6 (17,8) 3,31 8,3 (5,2) 1,66 16,4 (10,2)
4 1,418 18,2 (11,3) – – 2,37 11,5 (7,1) 0,84 31,9 (19,8)
5 0,944 27,2 (16,9) – – 1,66 16,4 (10,2) – –
6 0,611 41,5 (25,8) – – 1,19 22,7 (14,1) – –
7 – – – – 0,84 31,9 (19,8) – –
8 – – – – 0,603 43,9 (27,3) – –
Gear
ZF FUNK
Forward Reverse Forward Reverse
Ratio km/h (mph) Ratio km/h (mph) Ratio km/h (mph) Ratio km/h (mph)
1 5,202 5,4 (3,4) 4,933 5,5 (3,4) 6,54 4,3 (2,7) 6,54 4,3 (2,7)
2 3,367 8,1 (5) 2,078 13,1 (8,1) 4,68 6,0 (3,7) 3,31 8,4 (5,2)
3 2,191 12,4 (7,7) 0,895 30,3 (18,8) 3,31 8,4 (5,2) 1,66 16,7 (10,4)
4 1,418 19,2 (11,9) – – 2,37 11,8 (7,3) 0,84 32,5 (20,2)
5 0,944 28,7 (17,8) – – 1,66 16,7 (10,4) – –
6 0,611 44,1 (27,4) – – 1,19 23,1 (14,4) – –
7 – – – – 0,84 32,5 (20,2) – –
8 – – – – 0,603 44,8 (27,8) – –
Gear
ZF FUNK
Forward Reverse Forward Reverse
Ratio km/h (mph) Ratio km/h (mph) Ratio km/h (mph) Ratio km/h (mph)
1 5,562 4,5 (2,8) 5,274 – 6,01 4,3 (2,7) 6,01 4,3 (2,7)
2 3,615 6,9 (4,3) 2,138 – 4,28 6,0 (3,7) 3,07 8,4 (5,2)
3 2,255 11,1 (6,9) 0,894 – 3,07 8,4 (5,2) 1,51 16,9 (10,5)
4 1,466 16,9 (10,5) – – 2,19 11,7 (7,3) 0,777 32,4 (20,1)
5 0,942 25,9 (16,1) – – 1,51 16,9 (10,5) – –
6 0,613 38,8 (24,1) – – 1,08 23,4 (14,5) – –
7 – – – – 0,777 32,4 (20,1) – –
8 – – – – 0,552 44,7 (27,8) – –
