CHAPTER 2 – SAFETY / DECALS / HAND SIGNALS
2-14
SYMBOLS
Main Symbols used in this Manual
WARNING (Warning signal) DIFFERENTIAL LOCK
FUELING HOURMETER
AIR CLEANER RESTRICTION OPERATOR’S SEAT ADJUSTMENT
PARKING BRAKE LOCKED
HYDRAULIC OIL FILTER RESTRICTION UNLOCKED
TRANSMISSION OIL FILTER RESTRICTION BLADE FLOATATION (Right Cylinder)
BATTERY BLADE FLOATATION (Left Cylinder)
BRAKE OIL LOW PRESSURE FRONT BLADE FLOATATION
ENGINE WATER TEMPERATURE RIPPER
ELECTRICAL SYSTEM SCARIFIER
HYDRAULIC OIL TEMPERATURE SADDLE LOCK
TRANSMISSION OIL TEMPERATURE HORN
HAZARD WARNING LIGHTS RIGHT TURN SIGNAL
SUPPLEMENTAL STEERING LEFT TURN SIGNAL
LIGHTS LOW ENGINE RPM
LOW TRANSMISSION HYDRAULIC OIL
PRESSURE
HIGH ENGINE RPM
LOW ENGINE OIL PRESSURE
