Casio Exilim EX-Z1000

239
APPENDIX
Bottom
■ USB Cradle
Front
Back
bs
Battery/Memory Card Slots (pages 36, 47)
bt
Cradle Contact (page 38)
ck
Tripod Hole
Use this hole when attaching to a tripod.
cl
Speaker (page 140)
btckcl bs
1
Camera Contact (page 38)
2
USB Lamp
(pages 213, 227, 251)
3
[USB] Button
(pages 200, 213, 227)
4
[PHOTO] Button
(pages 146, 147)
5
[CHARGE] Lamp
(pages 38, 251)
6
[AV OUT] (AV output port)
(page 147)
7
[ ] (USB) Connector
(pages 198, 212, 226)
8
[DC IN 5.3V] (External Power)
Terminal (page 37)
