7. Things to think about
What transistor characteristics become evident from this experiment?
8. Write down your feelings about this experiment
9. Topic
A transistor works the same way as a vacuum tube. Summarize the difference between the
structure of a vacuum tube and a transistor.
10. Supplement
The 2SD1763 used in this experiment is a transistor that is used when large output is
required, such as for a speaker. This type of transistor is called a power transistor.
