22
Getting Started with Your Phone
1. Slide the Battery Cover Lock to the FREE
position in the direction of the arrow
shown in the figure to the right.
2. Insert your fingertip into the recess ,
and then pull the battery cover up in the
direction indicated in the figure to the right
.
3. Slide the battery into the slot by aligning the
contacts and tabs and press down until
you hear the “click”.
4. Place the battery cover properly on the
handset, then press down firmly on the side of
the battery cover at each arrow point, as
shown to the right.
5. Slide the Battery Cover Lock to the LOCK
position in the direction of the arrow
shown in the figure to the right.
Warning!
If you are using a wrist strap (sold separately), be careful not to get
it caught between the battery cover and the handset, in order to
maintain waterproofing.
