CEM EDGE system - Back and Side View

5Instrument Overview
Back and Side View
1
7
6
5
4
3
2
Item
1 Fuses/Fuse Holder
2 Power Inlet
3 Exhaust Assembly
4 Cooling Fan
5 Fluidics and Manifold
6 Solvent Lines
7 Waste (Vent, Drain & Sensor)
