MHO-170 Front Panel
Quantum Maestro Getting Started Guide|27
Item Description
8 Synchronization port 32 (colored purple).
You connect a DAC cable between ports 32 on two Quantum Maestro Orchestrators MHO-170
for redundancy on the same site.
9 RJ45 port with the label CONSOLE. See "Console Port" on page48 .
To this port you connect a client, from which you configure the Gaia Operating System on the
Quantum Maestro Orchestrator (in Gaia Clish).
Notes:
n
It is possible to connect DAC or Fiber cable (with transceivers) to each port (from 1
to 32).
n
It is possible to connect Breakout cables only to the top ports.
In this case, the bottom ports are disabled.
See "MHO-170 Splitting Options" on page85 .
