Mounting the Quantum Maestro Orchestrator MHO-140 and MHO-170 in a Rack
Quantum Maestro Getting Started Guide|70
Parts in the static rail kit:
Item Description
A 2 x Rack mount rails
B 2 x Rack mount blades that slide into the rack mount rails (A)
C 8 x M6 standard cage nuts, and 8 x M6 standard Phillips pan-head screws
D 4 x Phillips flat-head screws with a round patch, Head 100 Degree, Type I, Size 6-32,
Length 1/4 inch
E Rack mount rail ears
F Rack mount blade ears
Legend
