5.1.2 SYNTHESIS 14-18kVA
(At 25 °C, Nominal Line Voltage unless otherwise specified)
Output Power (kVA/kW): 14/9.8, 16/11.2, 18/12.6
Input Voltage: 208 or 240 VAC, 60 Hz, Single Phase Factory Wired
Output Voltage: 120/208/240V Single Phase Factory Wired
Output Frequency: 60 Hz ± 0.05%
Output Voltage Regulation: ± 6%
(Static)
Dynamic Output Voltage 5% (0-100% AND 100%-0 Load
Regulation: Variation)
(Over Static Regulation)
Charging Current: 3A
Efficiency:
Measured at Rated Load, 0.7 pf
Line Interactive Mode: 95%
Double Conversion Mode: 82%
5.2 MECHANICAL
5.2.1 SYNTHESIS 4-12kVA
Operating Temperature Range: 0 - 40°C (32 - 104°F)
(Temperatures above 25°C (77 °F) shorten battery life
and affect system warranty)
Cooling: Forced Air
Unit Size (kVA) 4.0
5.0 6.0 8.0 10.0 12.0
Heat Rejection
(BTU/Hr) 1430 1790 2140 2600 3250 3900
Weight (LBS)
(Std unit w/o Battery) 245 245 245 310 310 310
Dimensions:
Width 24.3” 24.3” 24.3” 29.8” 29.8” 29.8”
Depth 23.6” 23.6” 23.6” 29.5” 29.5” 29.5”
Height 30.3” 30.3” 30.3” 37.8” 37.8” 37.8”
53
