Chloride SYNTHESIS - Kva Spare Parts Listing

1 15B10654G1 AP6 RFI filter, class A
1 15B10658G1 AP2S* RFI Inverter Snubber Bd
*This board "piggybacks" on the inverter board
** Ref SIB B
6.2 8-12 kVA SPARE PARTS LISTING
8-12 kVA - Level 1
KIT P/N: SPK12KL1
Qty. Part number
CIRCUIT DESIGNATION
Description
2 00B46117PC060 FU3, FU6 Fuse, 60A, 500V, Extra Fast
2 10B46436PD80U QS5 Fuse, 80A, Extra Fast
5 10B46347P001 FU7, FU8 Fuse, 1A, 250V
5 10B46209P05R FU9 Fuse, 2A, 500V
5 10B46209P11R FU3, FU6 (AP1) Fuse, 8A, 500V
2 00B46030PF05T FU1 (AP2) 1 A Fuse
8-12 kVA - Level 2
KIT P/N: SPK12KL2
Qty. Part number Description
1 10B44112P1006 V5 IGBT, 2 x 100A, 600V
1 10B44112P1012 V7 IGBT, 2 x 100A, 1200V
1 10B44087P3 V6 Diode, ultra-fast, 2 x 60A,600V
2 00B44074PT312 V3, V8, V9 SCR, 55A
1 10B44114P02 V4 SCR, 90A, 1200V
1 10B48270P1 EV1 - EV3 Fan, EDP 50
8-12 kVA - Level 3
KIT P/N: SPK12KL3
Qty. Part number
CIRCUIT DESIGNATION
Description
1 15B10722G1 AP4 Micro board
1 15B10602G1 AP5 Boost Board, 12 kVA
1 15B10604G1 AP2 Inverter Board, 12 kVA
1 15B10606G4 AP1 Charger Board, 12 kVA
1 15B10724G1** AP3 Front panel board, 6K
1 15B10654G1 AP6 RFI filter, class A
1 15B10658G1 AP2S* RFI Inverter Snubber Bd
*This board "piggybacks" on the inverter board
** Ref SIB B
