Section 1: Introduction
Christie ACT User Manual 1-3
020-100129-05 Rev. 1 (02-2010)
1.2 Purchase Record and Service Contacts
Whether this product is still under warranty or the warranty has expired, Christie’s highly trained and extensive
factory and dealer service network is always available to quickly diagnose and correct malfunctions.
Should you encounter a problem with this product, please contact your dealer listed on the back cover of this
manual. If you have purchased the product, fill out the form below and keep with your records.
Table 1.1 Purchase Record
* The serial number can be found on the license label located on the side panel of the product.
1.2.1 RS232 IN Settings
Table 1.2 Serial Port Default Settings
Determine the IP Address Using the Serial Port
You can determine Christie ACT’s current IP address by connecting to Christie ACT using the RS232 IN port
and rebooting Christie ACT (reboot by unplugging the power cord and plugging it back in). As Christie ACT
boots up it will display the current Ethernet settings over the serial connection.
The Ethernet settings can also be queried by using these serial commands:
(net+eth0?) - query the current IP Address
(net+sub0?) - query the current Subnet Mask
(net+gate?) - query the current Gateway
Dealer/Christie Sales Contact:
Dealer/Christie Sales Contact Phone Number:
Christie ACT Serial Number*:
Purchase Date:
Installation Date:
RS-232 IN RS-232 OUT RS-422 RS-232 OUT
(Audio)
Baud Rate (Bits Per Second) 115,200 115,200 19,200 9,600
Data Bits 8 8 8 8
Parity None None None None
Stop Bits 1 1 1 1
Protocol Script
Protocol
Script
Protocol
Script
Protocol
Script
Protocol
Mode 8N1 8N1 8N1 8N1
Flow Control None None None None
