Chroma 63200 Series User Manual

High Power DC Electronic Load 63200 Series Operation & Programming Manual
12-6
B. The current shunt range is 250A. Input the resistance listed in Table 12-6 and press
LOAD ON/OFF to start the Load. Refer to the DMM (V) value and adjust the DC Power
Supply value to be the same as the previous test model, and then wait for 30 seconds.
Record the DMM (V) voltage passed through the Load input terminal and the DMM (I)
reading of shunt current. Use DMM (V)/DMM (I) to calculate the resistance and check
for the value that meets the specification.
Table 12-6
Model
Setting
Resistance(Ω)
DC POWER SUPPLY
Appropriate Value (Ω)
Voltage
Current
Low Limit
High Limit
63201
50 Ω
80V
1.6A
45.455 Ω
55.556 Ω
0.25 Ω
10V
40A
0.249 Ω
0.251 Ω
63202_500V
100 Ω
500V
5A
100.969 Ω
99.079 Ω
10 Ω
20V
2A
9.959 Ω
10.040 Ω
63202_600V
100 Ω
500V
5A
98.522 Ω
101.513 Ω
10 Ω
20V
2A
9.954 Ω
10.046 Ω
63203
25 Ω
80V
3.2A
22.553 Ω
28.043 Ω
0.125 Ω
20V
160A
0.1245 Ω
0.1255 Ω
63204_500V
100 Ω
500V
5A
98.039 Ω
102.041 Ω
5 Ω
20V
4A
4.980 Ω
5.020 Ω
63204_600V
100 Ω
500V
5A
98.039 Ω
102.041 Ω
5 Ω
20V
4A
4.980 Ω
5.020 Ω
63205
50 Ω
80V
1.6A
46.512 Ω
54.054 Ω
0.4 Ω
10V
25A
0.398 Ω
0.402 Ω
63206
50 Ω
80V
1.6A
40.700 Ω
64.809 Ω
0.125 Ω
10V
80A
0.12449 Ω
0.12551 Ω
63207
50 Ω
80V
1.6A
44.903 Ω
56.402 Ω
0.25 Ω
10V
40A
0.249 Ω
0.251 Ω
63208
50 Ω
80V
1.6A
40.866 Ω
64.392 Ω
0.125 Ω
10V
80A
0.12450 Ω
0.12551 Ω
63209
50 Ω
80V
1.6A
35.714 Ω
83.333 Ω
0.075 Ω
15V
200A
0.07469 Ω
0.07531 Ω
63210_500V
100 Ω
500V
5A
98.619 Ω
101.420 Ω
5 Ω
10V
2A
4.982 Ω
5.018 Ω
63210_600V
100 Ω
500V
5A
96.154 Ω
104.167 Ω
5 Ω
10V
2A
4.975 Ω
5.025 Ω
63211
500Ω
800V
1.6A
366.97 Ω
784.31 Ω
8 Ω
10V
1.25A
7.915 Ω
8.087 Ω
63212
500Ω
800V
1.6A
366.97 Ω
784.31 Ω
8 Ω
10V
1.25A
7.915 Ω
8.087 Ω
12.3.2.2 Checking for Low ohm Range
A. Press CR and RANGE to select CRL. The screen shows:
CRLA: 2.000Ω
CRLB: 1.000Ω
