Local Operation
L NOTICE
If you press ENTER key, and the blinking data dose not go to the next, change the
configuration setting Enter Data Next to YES.
Setting CR Values
The CR values for the selected channel are programmed by pressing MODE, ▲ and ENTER
keys. The resistance values can be programmed in low voltage (CRL) or high voltage (CRH)
range. The current is always in high range. ALL resistance levels are programmed in
ohms. The slew rate is in A/μS.
Following examples illustrate how to set the CR values of Load module for model 63303.
1. Select Range
Press MODE and ▲ or ▼ key to select CRL followed by ENTER key.
MODE SELECT
CRL
2. Set Resistor Level
There are 4000 discrete steps from 0 to full scale in each range. Set the main resistor
level1 (A) to 2 ohms by pressing 2, ENTER. Set the level2 (B) resistor to 1 ohm by
pressing 1, ENTER.
CCL1: 2.000Ω
CCL2: 1.000Ω
3. Set Slew Rate
There are 250 discrete steps in each range. Set the rise and fall slew rates to 0.1 A/μS
by pressing . , 1, ENTER for rise slew rate and . , 2, ENTER for fall slew rate.
CRL : 0.10A/μS
CRL : 0.20A/μS
Setting CV Values
The CV values for the selected channel are programmed by pressing MODE, ▲ and ENTER
keys. The voltage values can be programmed within one range. The voltage levels are
programmed in volts, and the response speed is programmed in fast or slow operation.
Following examples illustrate how to set the CV values of Load module for model 63303.
Select a channel first before going through the examples.
1. Select Range
Press MODE and use ▲ or ▼ key to select CR followed by ENTER key.
4-5
