NOTE: All dimensions are in millimeters.
• O/F = Over Flush
• U/F = Under Flush
• U/D = Up/Down
• F/A = Fore/Aft
DIMENSION DESCRIPTION GAP FLUSH
1 Hood to Grill Varies +/- 2.0 Inboard —
2
Upper Fascia Applique to
Headlamp
2.5 +/- 1.0 U/D
2.5 +/- 1.5 Cross Car
Applique O/F Inboard 4.0
+/- 1.5
Transition to U/F Outboard
4.0 +/- 1.5
3
Upper Fascia Applique to
Hood
Outboard 7.0 +/- 1.5 Applique U/F 5.0 +/- 1.5
4
Windshield to Body Side
Aperture
4.0 +/- 2.0
0.0 to seal
—
5 Windshield to Roof
4.0 +/- 1.5
0.0 to seal
Windshield U/F 1.5+/- 1.5
Transition to 2.0 +/-
1.5 Outboard
6
Front Power Sunroof
Glass to Roof
0.0 to seal
Front Sunroof Glass U/F
1.5 +/- 1.5
Consistent within 1.0
7
Front Power Sunroof
Glass to Fixed Sunroof
Glass
0.0 to seal
Front Sunroof Glass O/F
1.5 +/- 1.5
Consistent within 1.0
8
Fixed Sunroof Glass to
Roof
0.0 to seal
Front Sunroof Glass O/F
1.5 +/- 1.5
9
Rear Fixed Sunroof Glass
(front) to Roof
0.0 to seal
Rear Sunroof Glass U/F
1.5 +/- 1.5
10
Rear Fixed Sunroof Glass
(rear) to Roof
0.0 to seal
Rear Sunroof Glass O/F
1.5 +/- 1.5
11 Liftgate to Roof
7.0 +/- 1.0
Parallel within 1.0
Liftgate U/F 1.5 +/- 1.0
Consistent within 1.0
12
Liftgate to Body Side
Aperture
4.0 +/- 1.0
Parallel within 1.0
Liftgate U/F 5.0 +/- 1.0
13
Fuel Door to Body Side
Aperture
2.5 +/- 1.0
Consistent within 1.0
Fuel Door U/F 1.0 +/- 1.0
Consistent within 1.0
Character line 0.0 +/- 1.0
14
Body Side Aperture to Sill
Moulding
1.0 +/- 0.0
Body Side Aperture O/F
0.5 +/- 1.0 at front
Transition to 0.0 at rear
15
Sliding Door to Sill
Moulding
4.0
Parallel within 1.5
Sliding Door O/F 0.5 +/-
1.0
16
Sliding Door to Sill
Moulding
4.5 +/- 1.5
Parallel within 1.5
Sliding Door U/F 5.0 +/-
1.5
17 Front Door to Sill Moulding
4.5 +/- 1.5
Parallel within 1.5
Front Door U/F 2.0 +/- 1.5
at front
Transition to 6.0 at rear
18 Fender to Front Door
4.0 +/- 1.0
Parallel within 1.0
Fender O/F 0.5 +/-
1.0 below character line
0.0 +/- 1.0 at top
19
Charge Port Door to
Fender
2.5 +/- 0.5
Parallel within 0.5
Charge Port Door U/F
0.5+/-0.5
RU 31 - Collision Information 31 - 69
