Chrysler PACIFICA 2017 - Page 72

DIMENSION DESCRIPTION GAP FLUSH
39 Fender to A-pillar
2.0 +/- 1.0
Parallel within 1.0
Side to side within 1.0
0.0 +/- 1.0
40 Fender to Sill Moulding
2.0 +/- 1.0
2.5 at notch
0.0 +/- 1.0 at front
Transition to Fender U/F
1.5 at rear
41 Front Door to Sliding Door
5.0 +/- 1.0
Parallel within 1.0
Front Door O/F below
character line 0.5 +/- 1.0
Front Door above character
line 0.0 +/- 1.0
42
Front Door Applique to
Sliding Door Front
Applique
5.0 +/- 1.5
Parallel within 1.5
0.0 +/- 1.5
Consistent within 1.5
43
Sliding Door to Body Side
Aperture
4.0 +/- 1.0
Parallel within 1.0
Sliding Door O/F below
character line 0.5 +/- 1.0
Sliding Door above character
line 0.0 +/- 1.0
44
Sliding Door Rear
Applique to Quarter Glass
5.5 +/- 1.5
Parallel within 1.5
0.0 to seal
Applique O/F 3.5 +/- 1.5
Consistent within 1.5
45
Body Side Aperture to
Rear Fascia
F/A and U/D 0.0 to 0.5
Fascia at Taillamp U/F 0.5
+/- 0.5
Transition to 0.0 at
Wheelhouse
46
Tail Lamp to Body Side
Aperture
1.5 +/- 1.0
Consistent within 1.0
Lamp O/F 4.0 +/- 1.0 at
inboard
Transition to 4.5 to 4.0 at
top
47
Tail Lamp to D-pillar
Applique
4.0 +/- 1.5
Parallel within 1.5
Lamp Varies +/- 1.5
48 Tail Lamp to Liftgate Lamp
4.5 +/- 1.5
Parallel within 1.5
Side to side within 2.0
0.0 +/- 1.5 at top
Transition to Tail Lamp O/F
1.0 to 0.0 at bottom
49 Liftgate to Rear Fascia
4.0 +/- 1.5
Parallel within 1.5
—
50
Rear Fascia Applique to
Lower Fascia
0.5 +/- 0.5
Applique U/F 1.0 +/- 1.0
(Single Exhaust)
Applique O/F inboard 15.5
+/- 1.0 transition to
3.5 outboard (Dual Exhaust)
51
Rear Liftgate to Upper
Fascia
4.0 +/- 1.5
Parallel within 1.5
—
52
Rear Liftgate to Upper
Fascia
5.5 +/- 1.5
0.0 at top
Transition to Fascia O/F
3.0 at bottom
RU 31 - Collision Information 31 - 71
