Ciara Enterprise/Discovery 945GTP
- 16 -
Processor:
Intel Pentium
®
D (2.8 GHz to 3.2 GHz),
Intel Pentium
®
4 (2.8 GHz to 3.8 GHz) and
Celeron (2.53 to 3.2 GHz)
with LGA775 connector.
Bus:
Front side bus: 533, 800 or 1066 MHz.
One PCI Express x16 video slot, one PCI Express x1 expansion slot
and two conventional PCI slots.
System Board:
Intel D945GTP µATX format main board uses Intel 945G chipset
BIOS:
Intel/AMI Flash BIOS standard, with ACPI, APM, DMI, Energy Star,
Plug & Play and SMBIOS features.
RAM:
DDR2 240 pin Type PC400, PC533 or PC667 SDRAM, minimum
128MB and 4GB maximum. Four DIMM sockets. SPD (Serial
Presence Detect) memory is mandatory. Non-ECC memory only is
supported.
Ports:
One 9-pin serial port, one 25-pin Parallel port, PS/2 style mouse and
keyboard ports, video port, four USB 2.0 ports, audio ports, RJ45
port.
Drives:
3.5” 1.44 MB floppy drive, vast choice of EIDE CD-ROM drives and
vast choice of IDE Parallel ATA and Serial ATA hard disk drives.
The IDE controllers support two IDE devices at Ultra DMA
33/66/100.
Four Serial ATA controllers (3 Gbps) supporting one drive each.
Video:
Integrated Intel 82945G GMA950 video controller with 3-D
architecture, 32 bits per pixel graphics engine, 2-D acceleration, video
acceleration, MPEG 2 acceleration. DVMT technology enabling the
controller to use up to 224 MB of system memory. Two multiplexed
DVO port interfaces with 200 MHz pixel clocks using an ADD2 card
in the PCI Express x16 video slot.
Audio:
Integrated Intel High Definition Audio 6 (Sigmatel 9220 audio codec)
sound controller with audio in, audio out and microphone.
Network:
Integrated Intel 82562EZ Fast Ethernet network interface controller
10/100Mbits with WOL or Marvell Yukon 88E50 Gigabit
10/100/1000 Mbits with WOL.
Certification:
UL (E204926), FCC Class B, Microsoft (Windows 2000 and
Windows XP) certified, compliant with Energy Star guidelines for
energy efficiency.
Figure 1.3: Standard Features of Ciara Enterprise/Discovery 945GTP Computers
