7.3 : Opening and accessing the chassis
The front of the chassis, access to the front 5.25 and
3.5 bays, front panel USB and audio connectors and
power on button.
The side of the casing and a protective layer of blue
vellum for which protects the casings side, typically
the side where the casing lies during installation.
This picture shows the back of the casing, the rear
doors for peripheral installation, the back plate area
for which connectors related to the motherboard
(once installed) will be accessed, and the power
supply area.
A vertical lever for which once activated allows for
the unlocking of one panel side cover. Once
removed this will grant access to the inside of the
casing for modular installation.
