Ciara Enterprise/Discovery 945GTP
- 56 -
7.11: Connecting the keyboard
The depicted keyboard, a standard ACNOR
keyboard, which requires its removal from its
protective packaging.
The standard keyboard connector is as shown.
The keyboard connector is to be placed into its
designated area on the I/O back plate of the
chassis.
Connected keyboard.
