Ciara Enterprise/Discovery 945GTP
- 42 -
7.0: Quick installation guide
7.1: Mid-Tower Chassis Characteristics
Mid-Tower Specifications
Motherboard Type: ATX (12"x 9.6") or Micro ATX ( 9.6"x 9.6")
Drive Bay Space: Ext. 3 x 5.25", Ext. 2 x 3.5", Int. 2 x 3.5"
Power Source: 300 W
Peripheral Space: 2 PCI Express x1 slots, 4 conventional PCI slots and one
video PCI Express x16 slot
Dimensions (mm without bezel) : 425(H) x 198(W) x 465(D)
Front Fans: 1 x 80mm, 1 x 90mm, or 120mm
Rear Fans : 1 x 80mm, 1 x 90mm, or 120mm
Security: Lock and intrusion
Sheet Metal Thickness (mm): 0.8mm
Front
Rear
Side Internal
Security lock
Chassis intrusion
switch
Tool-less PCI slots
retention mechanism
