Chapter 4
Changing Symbology Settings
4.12 MSI
4.12.1 VERIFY CHECK DIGIT
Select one of the three calcul
ations to verify check digit
when de
coding barcodes. If
incorrect, the barcode will not be accepted.
Enable MSI
*
Disable MSI
*Single Modulo 10
D
ouble Modulo 10
Modulo 10 & 11
136
