175
Update
Chapter 6
Applying Formats for Data Editin
6.4.4 FIELD SETTINGS
Data eligible for editing formats is divided into fields by user-specified rules – either
using the field terminating string or specified field length.
By Terminating String
Specify the field terminating string. Up to two characters are allowed. The scanner will search for
the occurrence of this particular string in the data.
By default, this string will be included in the field. You may discard it.
By Length
Alternatively, you may simply specify the field length. The scanner will assign the next specified
number of characters into the field.
Field 1 Setting
1. Read the above label to divide field by a specified terminating string.
2. Read the “
Hexadecimal Value” label on page 206 for the desired character string.
3. Read the “Validate” label to complete this setting.
4. Read the “Discard Separator” label if the field separator is not desired in the field.
If not dividing the field by a specific separator, you may divide it by a specified length.
1. Read the above label to divide field by length.
2. Read the “
Decimal Value” label on page 205 for the desired field length.
3. Read the “Validate” label on the same page to complete this setting.
Select Field Separator
to Divide Field 1 …
*Include Separator
iscard Separator
Divide Field 1 by Length …
To Next Page
