131
Update
Chapter 4
Changing Symbology Settings
4.16 GS1 DATABAR (RSS FAMILY)
4.16.1 CODE ID SELECTION
Select a desired Code ID to use – GS1 DataBar Code ID "
]e0
” or GS1-128 Code ID "
]C1
".
4.16.2 GS1 DATABAR OMNIDIRECTIONAL (RSS-14)
Code ID Transmission
Decide whether to include the Code ID
in the data being transmitted.
Enable RSS-14 &
RSS Expanded
*Disable RSS-14 &
RSS Expanded
“]C1”
“
]e0” (Default)
*Transmit RSS-14 Code ID
D
o Not Transmit
142
144
