Appendix I Firmware Upgrade
HOW TO UPGRADE 3656 FIRMWARE
UPGRADING 3656 CPU FIRMWARE
1) Connect the interface cable, RS-232 or USB, between 3656 and your computer.
2) Connect the power supply cord from 3656 to a proper power outlet.
3) Refer to
3.1.1 Connect to 3656 for the target scanner to connect to 3656.
Read the “Set Connection” label first, and then the “Serial Number” label. Both labels
can be located at the back of 3656.
4) Read the following labels in sequence to configure the scanner to use RS-232 or USB
Virtual COM as output interface.
5) Read the following labels in sequence for 3656 to enter the download mode. The
Communication LED on 3656 will be flashing red to indicate it is ready for
downloading.
nter Setup
3656 Down
oad CPU Firmware
nter Setup
ctivate USB Virtual COM
pdate
Activate RS
32
To Next Page
