173
Update
Chapter 6
Applying Formats for Data Editin
6.4 CONFIGURING FORMAT — DEFINE DATA FIELD
6.4.1 START POSITION
Data can be divided into fields in one of the following direction –
from head (F1) to tail (F5)
from tail (F1) to head (F5)
6.4.2 FIELD ADJUSTMENT
You may apply equal length to all fields, if necessary. It will add “Space” (0x20) to field
when data is found shorter than specified.
1) Read the label above to adjust field by length.
2) Read the “
Decimal Value” label on page 205 for the desired field length.
3) Read the “Validate” label on the same page to complete this setting.
*From Head
From Tail
Set Length to adjust
ields …
*0
*No Adjustment
To Next Page
