172
End Programming Format
1560 Series Barcode Scanner User Guide
6.3.3 MATCHING STRING & LOCATION
By default, no matching string is specified, and therefore, it is disabled. You may enable
this feature by specifying a matching string; up to four characters are allowed.
When the Matching String Location is zero, the scanner will only check for the
existence of the matching string in the barcode data.
You may specify a value from 1 to 254 to indicate where the matching string starts in
the barcode data.
1) Read the label to specify a matching string.
2) Read the “Hexadecimal Value” label on page 206 for the desired character string.
3) Read the “Validate” label to complete this setting.
4) Read the label to specify the location of the matching string.
5) Read the “
Decimal Value” label on page 205 for the desired location.
6) Read the “Validate” label on the same page to complete this setting.
Matching String …
Location of
Matching String …
To Next Page
