Model Designation
8700 8770 8790
Bluetooth Class 2 √ √ √
802.11b/g √ √
Wireless
Communications
3.5G √
Barcode Reader
CCD (linear imager)
Standard Laser
Long Range Laser
2D Imager
Readers
RFID Reader Frequency 13.56 MHz
Main Battery Rechargeable Li-ion battery – 3.7 V, 4000 mAh
Working Time CCD, one scan per 5 seconds:
135 hours in batch mode (no communication
active)
112 hours in Bluetooth mode (power saving)
60 hours in Wi-Fi mode (1 broadcast packet per
second)
10 hours in 3G data connection
Backup Battery
Rechargeable Lithium button cell – 3.0 V, 7 mAh
Data retention – at least 25 days
Electrical
Characteristics
Power Adapter
Input: AC 100~240 V, 50/60 Hz
Output: DC 5 V, 3 A
Operating Temperature: 0 °C to 40 °C
CPU 32-bit Toshiba CMOS type, 40 MHz
Memory
Program memory – 8 MB flash
Data memory – onboard SRAM, 4 or 16 MB
Display Graphic LCD, 160 x 160 pixels, 3” FSTN with LED
backlight programmable
Font size 6x8: 26 characters by 19 lines
Font size 8x16: 20 characters by 9 lines
Overlaid with a touch screen that supports touch
control via stylus and signature capture.
Keypad 24-key or 44-key types, LED backlight programmable
Indicators
Two dual-color LEDs – red/green and blue/green,
programmable
Buzzer – 85db at 10 cm, 1 KHz, programmable
Physical
Characteristics
Vibrator 9000 ± 2000 RPM, Max. 50 dB, programmable
