11
This chapter walks you through the features and the functions that 8700 mobile
computers deliver. The 8700 lineup includes the following variations:
8700 Bluetooth Class 2
8770 Bluetooth Class 2 + 802.11b/g
8790 Bluetooth Class 2 + 802.11b/g + 3.5G
IN THIS CHAPTER
1.1 Battery..................................................................... 11
1.2 Memory.................................................................... 13
1.3 Keypad..................................................................... 14
1.4 LCD ......................................................................... 22
1.5 Notifications.............................................................. 24
1.6 Data Capture ............................................................ 25
1.7 Charging & Communications........................................ 30
1.8 SD Card ................................................................... 36
1.1 BATTERY
1.1.1 MAIN BATTERY
The mobile computer is fed by a rechargeable 3.7 V/4000 mAh Li-ion battery pack. When
the mobile computer is turned off, it takes approx. 5 hours to charge it to full from the
power adapter (using RS-232 cable or cradle) or approx. 14 hours from the USB cable (at
500 mA).
For power-saving purpose, always turn off the backlight while working in a well-lit area.
When the backlight is on for extended periods of time, the main battery will become low
sooner than expected.
The smart battery icon on the LCD screen shows the status of power consumption. There
are two ways to monitor the battery charge:
Examine the level of the 4-bar battery icon on the screen
Check up the voltage level by System Menu (see 3.5 Power)
Chapter 1
USING MOBILE COMPUTER
