8700 Series Mobile Computer Reference Manual
GETTING FAMILIARIZED WITH 8700
No. Description No.
Description
1 Scanning window 2 Stylus
3 LCD touch screen 4 LED for Good Read, battery charging and
wireless data connections
5 Keypad, 24 or 44 keys 6 Battery Latch
7 Li-ion Battery, fit to compartment 8 Direct data-transmission/charging port
Warning: Always make sure the hand strap is well hooked and screwed to the back
of the mobile computer before use.
Figure 1: Overview
