8700 Series Mobile Computer Reference Manual
1.4 LCD
The mobile computer ships with a 3” FSTN graphic LCD, 160 by 160 pixels resolutions,
which can be programmed to display text or graphics such as specific font and company
logo to meet various applications.
Options
Font Size (pixels) Characters by lines
English font Font size 6×8 (pixels)
Font size 8×16 (pixels)
26 characters by 19 lines
20 characters by 9 lines
Chinese font Font size 12×12 (pixels)
Font size 16×16 (pixels)
13 characters by 12 lines
10 characters by 9 lines
Other language fonts, company logo… Programmable
Note: The bottom line (ICON_ZONE) is reserved to display status icons, such as the
battery icon.
1.4.1 ADJUSTING THE BACKLIGHT
The backlight of screen and keypad makes it easier to operate the mobile computer in
dim environments. By pressing the following key combinations, LCD backlight can be
turned on/off and the brightness can be adjusted. Keep pressing the key combination
until the brightness or contrast decreases or increases to a desired level. Alternatively
the brightness and contrast are controllable through programming or via System Menu.
Refer to
3.2.2 Backlight and 3.2.13 Contrast.
Note: Using backlight on battery power will substantially reduce battery power. We
suggest that you dim the backlight while working in a well-lit area or set it to
automatic power off when the computer isn’t actively used.
Use the following key combinations to adjust the backlight for the mobile computer’s LCD
and keypad, and also the contrast for the LCD. Combine the keys by pressing the [fn]
key first and then pressing the second key.
Key Combination
Action
24-key 44 key
+ [Enter]
+ [Enter] Toggles on/off the backlight
+ [Up]
+ [Up] Increases the contrast of LCD
+ [Down]
+ [Down] Decreases the contrast of LCD
+ [Right]
+ [Right] Turns on the backlight and increases the brightness of
LCD/keypad backlight.
+ [Left]
+ [Left] Turns on the backlight and decrease the brightness of
LCD/keypad backlight.
+ [3] Same as + [Up]
