58
8700 Series Mobile Computer Reference Manual
SETTINGS
Interface
Options Description
RS232 Loading programs from RS232-interfaced devices such as your PC. The
mobile computer needs to connect to your PC with a RS232 cable.
Baud rate settings are necessary on both your PC and the mobile
computer.
USB VCOM Loading programs from USB-interfaced devices such as Your PC. The
mobile computer needs to connect to your PC with a USB cable.
Bluetooth Loading programs from Bluetooth-enabled devices.
SD Card Loading programs directly from the SD Card inserted in the mobile
computer.
USB VCOM_CDC Loading programs from USB-interfaced devices such as Your PC. The
mobile computer needs to connect to your PC with a USB cable.
Baud Rate
Available baud rate options: 115200/57600/38400/19200/9600 bps
LOAD PROGRAM VIA BLUETOOTH
3) Go to System Menu | 7. Bluetooth Menu | 3. Security, and configure the
following Bluetooth settings first.
Authentication
PIN code
4) Go to System Menu | 6. Load Program and select Bluetooth.
5) Have your PC initiate the pairing with the mobile computer by clicking [Pair Device]
and/or [Connect Bluetooth Serial Port].
6) On your PC, run the download utility ProgLoad.exe. In [Comm setting] group box,
make the following settings:
- Select RS-232 for [Comm type], so as to access Bluetooth SPP.
- Configure [COM port] properties according to the Bluetooth COM port generated
on your PC. Go to start | Control Panel | System | Hardware | COM & LPT to
check it up.
